Features


  • Drastically reduced size has been achieved by relocating the handle for easier operation even in tight spaces
  • Constant speed control minimizes the reduction in blade speed to provide stable cutting
  • BL motor delivers 3.2 m/s (630 ft./min.) blade speed for faster cutting
  • BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
  • Cutting capacity up to ø51 mm allows for single-pass cutting of ø50.8 mm pipe

Specification



Thumbnail
Model NameDPB184Z
Product Name18V Cordless Portable Band Saw
CapacityRound: 51 mm (2")
Square: 51 x 51 mm (2 x 2")
Blade SizeLength: 730 mm (28-3/4")
Width: 13 mm (1/2")
Thickness: 0.5 mm (0.02")
Blade Speed0 - 3.2 m/s (0 - 630 ft/min.)
Dimensions (L x W x H)373 x 162 x 223 mm (14-3/4 x 6-3/8 x 8-3/4")
Net Weight3.3 - 3.6 kg (7.3 - 7.9 lbs.)

Standard Equipment
Band Saw Blade, Hex Wrench

Available Option
Z: Without Charger & Battery

*Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.
