Product Detail
Features
- Powerful 1,500W motor delivers 4,200 RPM
- Compact and lightweight 14.7kg (32.5 lbs) for job site portability
- Dust bag for a cleaner work environment
- Electric brake for maximum productivity and increased operator safety
- See-through blade guard system for greater visibility of the line of cut
Specification
| Thumbnail |  |
| Model Name | M2300B |
| Product Name | Compound Miter Saw |
| Continuous Rating Input | 1,500 W |
| Guide Bar Length | 255 mm (10") |
| Miter Angle | 45° L / 45° R |
| Bevel Angle | 45° L |
| Max Cutting Capacity | 90° Miter: 75 x 130 mm (2-15/16 x 5-1/8") 45° Miter, L/R: 75 x 90 mm (2-15/16 x 3-9/16") |
| No Load Speed (RPM) | 4,200 |
| Dimensions (L x W x H) | 610 x 485 x 515 mm (24" x 19-1/8" x 20-1/4") |
| Net Weight | 14.7 kg (32.5 lbs.) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard equipment
Wrench, Dust Bag, Triangular Rule, Vise Assembly, Set Plate, Verticle Vise
Wrench, Dust Bag, Triangular Rule, Vise Assembly, Set Plate, Verticle Vise
*Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.
