Product Detail
Features
- Compact and Lightweight for Increased Jobsite Portability
- Four rails supported by linear ball bearings for smooth and accurate cuts
- Large aluminum base supports large stock for efficient cutting
- Powerful 1,010 W direct drive motor delivers 6,000 RPM
- Miters 0°-47° left and 0°-57° right; bevels 0°-45° left and 0°-5° right
Specification
| Thumbnail |  |
| Model Name | LS0714 |
| Continuous Rating Input | 1,010 W |
| Product Name | Slide Compound Saw |
| Blade Diameter | 190 mm (7-1/2") |
| Miter Angle | 47° L / 57° R |
| Bevel Angle | 45° L / 5° R |
| Max Cutting Capacity | 90°: 52 x 300 mm (2-1/16 x 11-3/4") 45°: 52 x 212 mm (2-1/16 x 8-3/8") |
| No Load Speed (RPM) | 6,000 |
| Dimensions (L x W x H) | 670 x 430 x 458 mm (26-3/8" x 17" x 18") |
| Net Weight | 13.1 kg (28.9 lbs) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard Equipment
Carbide-Tipped Saw Blade, Dust Bag, Holder Set, Vertical Vise, Triangular Rule
*Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.
