Product Detail


12Vmax Cordless Pruning Shears


  • Shear blade control is interlocked with Trigger for easier control of the blade
  • Electronic adjustment of blade opening angle and overlap when closed
  • Two control buttons on the tool body
    Main power button and Blade opening angle adjustment button are located side by side on the rear of the grip for easier blade control
  • Torque limiter
  • XPT (eXtreme Protection Technology)/IPX1-compatible for improved dust and water resistance for operation in harsh conditions
  • Battery protection circuit protects against overloading, over-discharging and over-heating



Model NameUP100DZ
Product Name12Vmax Cordless Pruning Shears
CapacityMax Cutting: 25 mm (1")
Dimensions (L x W x H)259 x 53 x 98 mm (10-1/4 x 2-1/16 x 3-7/8")
Net Weight0.89 - 1.1 kg (2.0 - 2.4 lbs.)
Work Amount (approx.)2,200 cuts with BL1021B
Cutting Ø15mm branches of Japanese Cypress

Standard Equipment
Oil Supply, Wrench Set, Dresser Stone Set (1912E4-1), Holster

Available Option
DZ: Without Charger & Battery
